TI-31SS

The TI-31SS is a self-locking internal push-on ring for a 0.312 inch housing diameter and is 0.01 inches thick. It is made from Stainless Steel PH15-7Mo, Passivated finish supplied by Rotor Clip. Made in USA

Details

Part# TI-31SS

Stainless Steel, Passivated
Manufactured by Rotor Clip
Made in USA

5/16 In. Housing Diameter, Self Locking Internal Push-On Ring
6 Prongs/ Teeth
0.136 In. Ring Inside Diameter
0.01 In. Thick

✅ RoHS Compliant ✅ REACH Compliant

Quantity discounts available

Quantity	Price
50 - 99	$0.9930
100 - 499	$0.4970
500 - 999	$0.3970
1000 - 4999	$0.3610
5000 - 9999	$0.3310
10000 +	$0.3060

8776 In Stock

(*) Minimun Quantity: 50

More information

Self-locking internal retaining rings can be installed in a housing/bore that has not had a groove machined into it. Self-locking rings with no lug holes are impossible to remove without either destroying the ring or warping it out of specified tolerances. This ring features a series of prongs protruding outward. The ends create interference with the housing when the ring is installed and a load is introduced to the other side.
