  • EN231, 2-5/16 in. External Notched Rings for Shaft Applications

Constant Section External Ring EN231 has external notches for pliers and is designed for use on 2-5/16 shaft applications. This ring is made from Carbon Steel with Plain & Oil finish.

Details

Details

External Ring# EN231
Includes External Notches
Carbon Steel SAE 1060/1075, Plain

2.312 In. Shaft Diameter
58.7 mm Shaft Diameter
2.158 In. Inside Diameter
0.078 In. Wire Thickness
0.203 In. Section Width

Recommended Groove Size
2.178 In. Diameter
0.067 In. Depth
0.086 In. Width
QuantityPrice
10 - 99$4.4000
100 - 499$2.2000
500 - 999$1.7600
1000 - 4999$1.6000
5000 - 9999$1.4670
10000 +$1.3540

4809 In Stock

(*) Minimun Quantity: 10

More information

Eaton Style external notch constant section retaining ring # EN231. A retaining ring is a fastener that holds components or assemblies onto a shaft or in a housing/bore when installed in a groove. Once installed, the exposed portion acts as a shoulder which retains the specific component or assembly.
